Cylinder Tag

Available in various different sizes and shapes. Protection IP 67.

Electrical Characteristics
Operating Frequency					125 KHz /13,56 MHz
IC Technologies					NXP, LEGIC, EM MARIN, ATMEL
Memory Size					Depends on IC type
Thermal and Environmental Characteristics
Storage Temperature					-40ºC up to +100ºC
Operating Temperature					-40ºC up to +85ºC
Packaging Protection Class					IP 67
Shock and Vibration					IEC 68-2-6 / 29
RoHs Compliance					YES
Physical Characteristics
Available Size	44,50 mm	46 mm	52 mm	56,50 mm	62,50 mm	72 mm	77,50 mm
Outer Diameter	44,50 mm	46,0 mm	52,0 mm	56,50 mm	62,50 mm	72,0 mm	77,50 mm
Inner Diameter	28,0 mm	30,0 mm	35,0 mm	40,0 mm	45,0 mm	54,50 mm	60,0 mm
Thickness	3,0 mm	3,0 mm	3,25 mm	3,0 mm	3,0 mm	3,0 mm	3,0 mm
Weight (approx.)	3,8 g	4,0 g	4,6 g	5,2 g	6,0 g	8,0 g	9,0 g
Material	Special Thermoplastic + Epoxy
